Detail View - 106056

item-image

gas tap PEL type 22S/O gas inlet M20x1.5 (tube ø 12mm)

Part Code 106056

Franke, Salvis

Technical Details
Spare parts
Accessories

type	22S/O
bypass nozzle ø	0,35 mm
gas inlet	M20x1.5 (tube ø 12mm)
gas outlet	M20x1.5 (tube ø 12/10mm)
thermocouple connection	M10x1
pilot connection	M10x1
shaft diameter	6x4.6 mm
shaft length	45/20 mm
shaft flat	left
producer	PEL

magnet unit L 39mm D1 ø 15,4mm D2 ø 13,5mm suitable for PEL22/EGA24197

Part Code 101058

gas tap front part shaft ø 6x4.6mm shaft L 45/20mm shaft flat right/left suitable for PEL22

Part Code 101213

gas connection thread M20x1.5 tube ø 12/10mm for PEL gas taps with gasket and screws horizontal

Part Code 101240

thermocouple nut T1: M10x1 T2: M18x1 suitable for PEL20/21

Part Code 101290

O-ring suitable for PEL22 ø 12,37mm D1 ø 2,62mm

Part Code 101460

screw suitable for PEL22 kit Qty 4 pcs

Part Code 101461

union screw for pipe ø 4mm thread M10x1 Qty 1 pcs VPE 1 Stück

Part Code 100908

union screw for pipe ø 6mm thread M10x1 ID ø 6,2 mm L 12 mm WS 10 Qty 1 pcs

Part Code 100909

gas connection thread M20x1.5 tube ø 12/10mm for PEL gas taps vertical

Part Code 101241

olive for pipe ø 4mm Qty 1 pcs

Part Code 101246

olive for pipe ø 12mm L 9,5mm brass Qty 1 pcs suitable for PEL

Part Code 101248

olive for pipe ø 10mm Qty 1 pcs

Part Code 101249

union nut thread M20x1.5 for pipe ø 10mm

Part Code 101250

union nut thread M20x1.5 for pipe ø 12mm

Part Code 101251

olive ID ø 6mm Qty 1 pcs

Part Code 101286

knob ø 70mm shaft ø 10x8mm

Part Code 110080

knob dial plate silver gas tap PEL21/22/23 ED ø 63mm ID ø 45,5mm

Part Code 112206
