timer MS65 operation time 120min time spread 30min 1CO/2NO/1NC at 250V 16A impulse electric
Part Code 350074
Suitable for the following brands
Emmepi, Inoxtrend, Krefft, Küppersbusch, Lincat, Modular, Piron, Rosinox, Tecnoinox, VENIX, Whirlpool
- Technical Details
| type | MS65 |
| operation time | 120min |
| function | 1CO/2NO/1NC |
| permanent position | yes |
| shaft length | 22 mm |
| connection | lateral |
| number of poles | 4 -pole |
| shaft position | lower ° |
| mounting distance | 28 mm |
| version | - |
| time spread | 30 min |
| producer | Invensys |
| shaft diameter | 6x4.6 mm |
| impulse | electric |
| switch power at 250V | 16 A |
