thermostat t.max. 90°C temperature range 0-90°C 1-pole 1CO 16A probe ø 6,5mm probe L 87mm
Part Code 390465
Suitable for the following brands
Elviomex-Alfa
- Technical Details
| temperature max. | 90 °C |
| number of poles | 1 -pole |
| function | 1CO |
| switching capacity | 16 A |
| probe diameter | 6,5 mm |
| probe length | 87 mm |
| capillary pipe length | 1470 mm |
| gland nut | - |
| shaft diameter | - mm |
| operating temperature range | 0-90 °C |
| capillary pipe length insulated | 1450 mm |
| rotation angle | 270 ° |
| type | 95 |
| producer | CAMPINI |
| shaft position | - |
| probe material | copper |
