heating element 2600W 230V heating circuits 2 mounting ø 42mm hole distance 74mm L 330mm W 30mm
Part Code 417001
Suitable for the following brands
Ascaso, Brasilia, Faema, Futurmat, Iberital-Macchine, Italcrem, Mairali, Visacrem
- Technical Details
- Alternative items
- Accessories
| power | 2600 W |
| voltage | 230 V |
| length | 330 mm |
| length 1 | 23 mm |
| length 2 | 65 mm |
| length 3 | 202 mm |
| height 1 | 30 mm |
| height 2 | 30 mm |
| mounting | 2 hole flange |
| connection | M6 |
| tube diameter | 8,5 mm |
| heating circuits | 2 |
| hole distance | 74 mm |
| height | 60 mm |
| mounting diameter | 42 mm |
| width | 30 mm |
| hole diameter | 12 mm |
| diameter thermostat sleeves | 7 mm |
| number of thermostat sleeves | 1 |
| length thermostat sleeves | 195 mm |
| position thermostat sleeve | eccentric, non clinging |
| application | immersion heater |
| weight | 0,600 kg |
