Detail View - 690050

360° image

walk-in fridge catch type JUMBO 6000 locking version L 300mm H 70mm W 40mm

Part Code 690050

installation-/conversion instructions

File	Language
Montage-/Umbauanleitung.pdf	Deutsch
installation-/conversion instructions.pdf	Englisch

Catalogue / Data sheet

File	Language
Produktkatalog/Datenblatt.pdf	Deutsch

Technical Details
Alternative items
Spare parts
Accessories

colour	chrome-plated
height	70 mm
length	300 mm
width	40 mm
version	locking version
for	refrigeration
accessories	with 2 keys
application	-
type	JUMBO 6000
no.	6000-020893
hinging	right/left

walk-in fridge catch type JUMBO 6000 locking version L 300mm H 70mm W 40mm

Part Code 692917

spring for trap L 40mm ø 14mm wire gauge ø 2mm

Part Code 690238

castor

Part Code 692761

door opener for door thickness 40-56mm no. 6000-020530 green for 6000/6004 series

Part Code 694025

spring for push-button L 35mm ø 14,5mm wire gauge ø 1,2mm

Part Code 698666

key cylinder shaft ø 12mm W 15,75mm L 27mm H 25mm ED ø 15,8mm thickness 2,5mm type 6000/6004

Part Code 700722

spare keys for JUMBO 6000 501

Part Code S0090139

door catch for off-set 26-35mm walk-in fridge mounting distance 30mm W 61mm L 60mm H 41mm

Part Code 690051

base plate shaft ø 13mm walk-in fridge L 84mm W 40mm H 20,5mm thickness 6mm type JUMBO 6000

Part Code 690052

base plate walk-in fridge mounting distance 25mm L 48mm W 40mm H 8mm thickness 6mm type JUMBO 6000

Part Code 690053

counter support for off-set 0mm mounting distance 37x14mm W 30mm L 50mm H 28mm

Part Code 690054

counter support for off-set 13mm mounting distance 14,25mm W 28mm L 52mm H 46mm

Part Code 690056

counter support for off-set 16mm mounting distance 14,25mm W 28mm L 52mm H 49mm

Part Code 690057

counter support for off-set 19mm mounting distance 14,25mm W 28mm L 52mm H 50mm

Part Code 690058

door catch for off-set 30-43mm walk-in fridge mounting distance 30mm W 61mm L 60mm H 47mm

Part Code 690060

base plate walk-in fridge L 53mm W 56mm H 7mm thickness 0mm mismatch 43x23mm type JUMBO 6000

Part Code 690061

base plate walk-in fridge mounting distance 43x23mm L 59mm W 61mm H 29mm

Part Code 690062

base plate refrigeration mounting distance 43x23mm L 59mm W 61mm H 49mm thickness 42mm

Part Code 690063

base plate walk-in fridge mounting distance 43x23mm L 59mm W 61mm H 9mm

Part Code 690064

base plate walk-in fridge mounting distance 43x23mm L 59mm W 61mm H 69mm

Part Code 690065

door opener for door thickness 60-76mm no. 6000-020531 green for 6000/6004 series

Part Code 690066

door opener for door thickness 76-92mm no. 6000-020532 green for 6000/6004 series

Part Code 690067

door opener for door thickness 92-108mm no. 6000-020533 green for 6000/6004 series

Part Code 690068

door opener for door thickness 108-124mm no. 6000-020534 green for 6000/6004 series

Part Code 690069

door opener for door thickness 124-140mm no. 6000-020535 green for 6000/6004 series

Part Code 690070

door opener for door thickness 140-156mm no. 6000-020536 green for 6000/6004 series

Part Code 690071

door opener for door thickness 156-172mm no. 6000-020537 green for 6000/6004 series

Part Code 690072

base plate refrigeration W ø 59mm H 5mm ED ø 59mm thickness 5mm type 6000/6004 green no. 6000-020615

Part Code 690073

door catch upper JUMBO 6000 mounting distance 30mm W 61mm L 60mm H 48mm

Part Code 692885

walk-in fridge catch type JUMBO 6000 locking version L 300mm H 70mm W 40mm
