Detail View - 102831

item-image

360° image

pilot burner SIT type 140 series 2 flames

Part Code 102831

Küppersbusch, Küppersbusch, SIT, Thielmann

Technical Details
Spare parts
Accessories

type	140 series
flame number	2 flames
producer	SIT

ignition electrode connection M4 Qty 1 pcs

Part Code 100701

igniter screw thread M10x1 brass ID ø 7,2 mm L 11 mm WS 10 Qty 1 pcs

Part Code 100906

screw connection for thermocouple thread M10x1 type SEF 1 Qty 1 pcs

Part Code 100907

pilot burner nozzle LPG code 14 bore ø 0.18/0.20mm SIT suitable for 140 series

Part Code 100204

pilot burner nozzle LPG code 19 bore ø 0.23/0.26mm SIT suitable for SIT 150 series

Part Code 100205

pilot burner nozzle natural gas code 36 bore ø 0.60/0.55mm SIT suitable for SIT 150 series

Part Code 100206

pilot burner nozzle natural gas code 27 bore ø 0.40/0.38mm SIT suitable for SIT 140 series

Part Code 100207

pilot burner nozzle SIT natural gas code 38 bore ø 0,45mm Qty 1 pcs

Part Code 100216

olive for pipe ø 4mm for pilot burner Qty 1 pcs VPE 1 Stück

Part Code 100897

olive for pipe ø 6mm Qty 1 pcs for pilot burner für Zündbrenner

Part Code 100898

union screw for pipe ø 4mm thread M10x1 Qty 1 pcs VPE 1 Stück

Part Code 100908

union screw for pipe ø 6mm thread M10x1 ID ø 6,2 mm L 12 mm WS 10 Qty 1 pcs

Part Code 100909
