gas thermostat PEL type 24STS 100-300°C gas inlet M20x1.5 (tube ø 12/10mm)
Part Code 106027
Suitable for the following brands
Küppersbusch, Küppersbusch
Available here for download:
Deutsch
Englisch
- Technical Details
- Spare parts
- Accessories
| type | 24STS |
| temperature range | 100-300 °C |
| gas inlet | M20x1.5 (tube ø 12/10mm) |
| bypass nozzle ø | 0 mm |
| gas outlet | M20x1.5 (tube ø 12/10mm) |
| thermocouple connection | M9x1 |
| pilot connection | M10x1 |
| shaft diameter | 10x8 mm |
| shaft length | 27/17 mm |
| shaft flat | upper |
| capillary pipe length | 1200 mm |
| probe diameter | 6 mm |
| probe length | 100 mm |
| temperature max. | 300 °C |
| producer | PEL |
| weight | 0,945 kg |
